How Does a Radiator Work?

Aug 4, 2021 ·
A new career path starts here

It only takes a few minutes to learn about technician training opportunities.

LAST STEP!

Tell us a bit about yourself so we can find the campus nearest to you.

Required
Required
Required
Required
Required
Required
Please enter your email address

By submitting this form, I agree that Universal Technical Institute, Inc., Custom Training Group, Inc., and their representatives may email, call, and / or text me with marketing messages about educational programs and services, as well as for school - related communications, at any phone number I provide, including a wireless number, using prerecorded calls or automated technology. I understand that my consent is not required to apply, enroll or make any purchase.

By submitting this form, I further understand and agree that all information provided is subject to UTI's Privacy Policy available at uti.edu/privacy-policy

There’s an entire cooling system at work under the hood of your car that helps it operate efficiently without overheating. The engine gets very hot while running, so the temperature must be regulated to prevent damage.

There are many parts that make up this cooling system, including the water pump, thermostat, hoses, fans and the radiator. The radiator is a heat exchanger that helps cool the engine.

Keep reading to find out more about how this part works and why it’s so important to the operation of your vehicle.

What Is a Radiator?

The radiator helps keep your vehicle cool, but how exactly does it achieve this goal?

The engine in a vehicle burns fuel and creates energy, which generates heat. Venting this heat away from engine parts is important to prevent damage.

Radiators work to eliminate heat from the engine. The process begins when the thermostat in the front of the engine detects excess heat. Then coolant and water get released from the radiator and sent through the engine to absorb this heat.

Once the liquid picks up excess heat, it is sent back to the radiator, which works to blow air across it and cool it down, exchanging the heat with the air outside the vehicle.

The radiator utilizes thin metal fins during the process, which are effective at allowing heat to quickly escape to the air outside the car. These fins are often working alongside the fan that’s blowing air across the radiator.

Long story short, the answer to “What’s a radiator in a car?” is simple — It is a heat exchange that cools fluid, which cools down the engine.

Where Is the Radiator in a Car?

The radiator is located under the hood and in front of the engine. The coolant reservoir is located next to these components as well.

What Does a Radiator Look Like?

Here’s a diagram of a vehicle’s engine cooling system, including what a radiator looks like:

Image credit: mechanicalbooster.com


Parts of a Radiator

There are a few main parts that make up the radiator, and each plays a role in the cooling process. They are:

  • Core: The core is the largest part of the radiator. It’s a metal block that features the metal cooling fins that help vent the air. The core is where hot liquid releases heat and gets cooled before being sent through the process again.

  • Pressure cap: The pressure cap works to help seal the cooling system so it can remain pressurized. Coolant in the radiator is pressurized to prevent the coolant from boiling. It also keeps the system more efficient.
  • Inlet and outlet tanks: These tanks are where coolant flows in and out of the radiator and are located in the radiator head. Hot liquid flows from the engine through the inlet tank, and once it is cooled, goes out through the outlet tank and back into the engine.

  • Radiator hoses: Coolant moves through the engine via the radiator hoses. They are important for connecting the inlet and outlet tanks to the radiator and the engine.

Other Important Cooling System Parts

There are other important cooling system parts that work alongside your radiator, including the water pump and the thermostat.

As mentioned earlier, the thermostat regulates the engine’s temperature. If the engine needs to be cooled, the thermostat will open to allow an influx of coolant. It closes if the engine is at the proper operating temperature.

The water pump pushes the coolant through the system. This component is usually operated by the engine drive belt, which turns on the pump, and spinning blades force liquid through the system as needed. Gaskets and seals keep the coolant contained.

Coolant is also extremely important — it’s the fluid that gets pumped through the cooling system to prevent the engine from overheating. It also helps lubricate the different parts it contacts. You can read more about how coolant works here.

Signs of a Failing Radiator

Over time, different parts of the cooling system can begin to wear down. For a more general overview, read up on the most common cooling system problems.

A few signs that your radiator specifically is having issues can include:

  • Leaking coolant: Cracks or leaks in the radiator will cause coolant to appear on the ground underneath your vehicle. This can happen when your vehicle is parked or when you’re driving. If you notice this or low coolant levels, you might have a crack in your radiator.
  • Discolored coolant or sludge: Coolant is usually a thin consistency and colored green or yellow. Rust and debris from a failing radiator might cause contamination in the fluid that can turn it a dark or rusty color. It also might become thicker and create sludge, which can prevent it from cooling the engine.
  • Overheating: A vehicle consistently overheating could be a radiator issue, since the radiator is the way engine heat is removed.

  • Bent or damaged fins: Airflow can get blocked to the radiator if the fins on it get bent or damaged. This can be caused by gravel hitting them while driving or if too much water pressure is used while cleaning them.

Learn to Work on Car Cooling Systems at UTI

You can learn all about the maintenance and repair of a range of vehicle systems, including cooling systems, when you enroll in the Automotive Technology program at Universal Technical Institute (UTI).

Courses in UTI’s 51-week program can teach you the skills needed for an in-demand career in the industry.1 You’ll learn how to diagnose cooling system problems and how to work specifically on radiators.

Get the experience employers are looking for when hiring automotive technicians, and gain knowledge you could use to make repairs on your own vehicle. Request more information today!
